Ford Flex, Taurus SHO, Lincoln MKS/T & Explorer

Seventeen years after bringing the first big brake kits to the Gen I and Gen II SHO owners once again..... TCE delivers the goods. Back in the day the old SHO was looked upon to have big brakes with our 12.2" rotors and Superlite IIA calipers. My how things have changed! Today TCE presents massive 14.25" rotors and the latest in dual purpose calipers; the W4A. Full blown radial mount design combined with a massive caliper body the W4A sets the standard for this level of caliper. Larger caliper bodies, more pad cubic inches and a larger foot print mean long life, durable and responsive braking. Over, and over, and....This kit is a direct bolt on to the front of the 2010+ Flex, MKS, Taurus and Explorer.

FRONT KITS: 2010-2013

Plus 1: The 14.25" W4A Kit  $1695

  • Wilwood W4A differential bore calipers (4 piston)
  • Choice of BLACK or RED powder coat finish
  • Wilwood 14.25 x 1.25" GT rotors
  • Gas slotted
  • Wilwood billet aluminum rotor hats
  • TCE spec radial mount brackets featuring ARP studs
  • BP10 pads
  • Stainless Steel braided hoses (2)
  • All necessary mounting hardware
  • Optional Drilled and Slotted rotor finish- ADD $135
  • UPSIZE to 15" Rotors- $65

Application:  New for late 2010 the new TCE front Big Brake Kit for SHO packs all the performance and value you've come to expect. The huge 14.25" rotor provide greater heat sink capacity for long lasting fade resistance. Combined with the power and mass of the W4A caliper you get sure footed response and feel time and time again.



Fit: Requires 18" or larger wheels. Please see the wheel fit page for more info on required space. 20" stock SHO wheels require 10mm wheel spacer. Optional 15" rotors require 19" or larger wheels.



Notes: Stock wheels require wheel spacers.

REAR KITS: 2010+

Plus 1: The 14.25" W4A Kit  $1595

  • Wilwood W4A equal bore calipers (4 piston)
  • Choice of BLACK or RED powder coat finish
  • Wilwood 14.25 x 1.10" GT rotors
  • Gas slotted
  • Wilwood billet aluminum rotor hats
  • TCE spec radial mount brackets featuring ARP studs
  • BP10 pads
  • Stainless Steel braided hoses (2)
  • All necessary mounting hardware
  • Optional Drilled and Slotted rotor finish- ADD $135

Application: A NON parking brake rear kit to compliment our large front kit! This kit uses the W4A radial mount caliper but with proper size pistons for a rear application. The rotors are also 14.25" but a bit narrower helping to keep the weight off.



Fit: Requires 18" or larger wheels. Required spacing is the same as the front kit for spoke clearance. 20" stock SHO wheels require 10mm wheel spacer. Minor CLEARANCE GRINDING required for bracket fit.



Notes: Wheel spacers required. No parking brake. This is not an option- it is without only!
