Taurus SHO, Ford Flex, Explored Sport and Lincoln MKS, MKT

Seventeen years after bringing the first big brake kits to the Gen I and Gen II SHO owners once again..... TCE delivers the goods. Back in the day the old SHO was looked upon to have big brakes with our 12.2" rotors and Superlite IIA calipers. My how things have changed! Today TCE presents massive 15" rotors and the latest in dual purpose calipers; the W4A. Full blown radial mount design combined with a massive caliper body the W4A sets the standard for this level of caliper. Larger caliper bodies, more pad cubic inches and a larger foot print mean long life, durable and responsive braking. Over, and over, and....This kit is a direct bolt on to the front of the 2010+ Flex, MKS, Taurus and Explorer.

FRONT KITS: 2011-2019

The 15" Aero4 Front Kit

  • Wilwood Aero4 differential bore calipers (4 piston)
  • Choice of BLACK or RED powder coat finish
  • Wilwood 15 x 1.25" GT rotors
  • Gas slotted
  • Wilwood billet aluminum rotor hats
  • TCE spec radial mount brackets
  • BP10 pads
  • Stainless Steel braided hoses (2)
  • All necessary mounting hardware
  • Optional Drilled and Slotted rotor finish

Application:  New in late 2010 the TCE front Big Brake Kit for SHO packs all the performance and value you've come to expect from TCE. The huge 15" rotor provide greater heat sink capacity for long lasting fade resistance. Combined with the power and mass of the Aero4 caliper you get sure footed response and feel time and time again.



Fit: Requires 19" or larger wheels. Please see the wheel fit page for more info on required space.



Notes: Stock SHO wheels require wheel 10mm spacers. 14.25" front kit for 18" wheels available by special order.

SHO, Flex, Ex Spt 15" Aero4 Front



REAR KITS: 2011-2019

The 14.25" Aero4 Rear Kit

  • Wilwood Aero4 equal bore calipers (4 piston)
  • Choice of BLACK or RED powder coat finish
  • Wilwood 14.25 x 1.10" GT rotors
  • Gas slotted
  • Wilwood billet aluminum rotor hats
  • TCE spec radial mount brackets
  • BP10 pads
  • Stainless Steel braided hoses (2)
  • All necessary mounting hardware
  • Optional Drilled and Slotted rotor finish

Application: A NON parking brake rear kit to compliment our large front kit! This kit uses the Aero4 radial mount caliper but with proper size pistons for a rear application. The rotors are also 14.25" but a bit narrower helping to keep the weight off.



Fit: Requires 18" or larger wheels. Required spacing is the same as the front kit for spoke clearance. 20" stock SHO wheels require 10mm wheel spacer. Minor CLEARANCE GRINDING required for bracket fit.



Notes: Wheel spacers required. No parking brake. This is not an option- it is without only!

SHO, Flex, Ex Spt 14.25" Aero4 Rear



THE FINE PRINT:

FITMENT:  It is up to the consumer to verify proper vehicle and wheel fit. Wheel clearance requirements can be found on the WHEEL FIT page in the TOOLBOX above. If you are unsure of the fit or application please call or email prior to ordering. TCE makes no guarantee of wheel clearance.

TERMS AND CONDITIONS: All sales subject to 20% restocking fee. Return shipping is on you. No credit will be given for installed, mishandled or damaged goods.

SHIPPING: Shipping charges will be applied in the Shopping Cart prior to check out. Prices are based on an average delivery zone. Additional shipping charges may apply to AK, CA and HI. Call before you order for details.
